3-5T/H Sand Cement Adhesive Dry Mortar Mixing Plant Simple Dry Powder Mixing Machine

Place of Origin China
Brand Name CINACHARM
Certification CE ISO BV SGS
Model Number 3-5T/H
Minimum Order Quantity 1 set
Price Negotiable
Packaging Details China Standard Package
Delivery Time 30 working days after we got advanced payment
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 30 sets per month
Product Details
Features Easy Operation Brand Name Cinacharm
Weight 4000 Kg Power 23.5kw
Condition New Packaging 10-50kg/bag
Certification CE BV ISO Color Customer's Request
High Light

5T/H Dry Mortar Mixing Plant

,

Cement Adhesive Dry Mortar Mixing Plant

,

3T/H Dry Powder Mixing Machine

Leave a Message
Product Description

sand cement adhesive mortar mixing plant mortar mix simple dry powder mixing machine

3-5T/H Dry powder mortar mixer of Introduction:

The dry powder mixer mixes materials efficiently and quickly. Under the movement of the spiral belt of the mixing shaft, the inner and outer spiral belts turn the material in a larger range. The inner spiral belt moves the material to both sides, and the outer spiral belt moves the material from both sides to the inside. The movement causes the materials to be mixed back and forth, and some of the materials are pushed by the spiral belt and move in the axial and radial directions, thus forming a convection cycle. Due to the above-mentioned movement of stirring, the materials are quickly and uniformly mixed in a short time.

3-5 t/h dry mortar production line Details:

1) Small investment and best for individuals.
2) Small footprint, ordinary houses can build the factories.
3) Easy to operation, 2-3 people can make it. .
4) High yield, the output is 3-4T/H usually, to reach 20-25T per day.
5) Easy to operation and maintenance.

Introduction of Mortar Manufacturing Machinery:
I. Additionally equipped with secondary screw conveying system, finished product storage silo, automatic packing machine based on multi spiral ribbon mixer, to composed an efficient and reasonable simple dry powder mortar mixer with low cost.
II. Occupation Area<20m2, Height <3.5m, its capacity at 25-30t per day, just only need 2-3 person,very easy to operate.

3-5 t/h dry mortar production line parameter:

Dry mortar plant
Data
Power
Primary feeder
Diameter 165mm, length 3.2m
3kw
Dry mortar mixer
3.3m*1.05m*2m
7.5kw
Secondary feeder
Diameter 165mm, length 3m
3kw
Hopper
Diameter 1.6m, length 2.8m
/
Air compressor
/
4kw
Simple duster
Bag duster
3kw

Raw Materials of simple tile grout making machine:
I Cementing materials: cement, lime, gypsum.
II Aggregate: yellow sand, quartz sand, limestone, dolomite, expanded perlite, etc.
III Mineral admixture: industrial byproduct, industrial slag, fly ash, pozzolana, fine silica powder, etc.
IV Water-retention and thickening material.
V Chemical additives.

Mobile Concrete Batching Plant Of Details:

3-5T/H Sand Cement Adhesive Dry Mortar Mixing Plant Simple Dry Powder Mixing Machine 03-5T/H Sand Cement Adhesive Dry Mortar Mixing Plant Simple Dry Powder Mixing Machine 1

3-5T/H Sand Cement Adhesive Dry Mortar Mixing Plant Simple Dry Powder Mixing Machine 2






FAQ

Q1: Are you a trading company or factory?
A1: We are factory and Zhengzhou XingChang Import&Export Co. Ltd(CINACHARM) is the trade company of the factory;

Q2: How to choose the preferrable concrete mixer?
A2: Please just tell us the machine capacity.

Q3: What's the payment method?
A3: We accept T/T, L/C etc. Q4: How long is the delivery time? A4: Generall speaking, the products are in stock; If not, it needs about 7~10days; Please send us emails for more questions!

Q4: How long is the delivery time?
A4: Generall speaking, the products are in stock; If not, it needs about 7~10days;

Please send us emails for more questions!
